DZL Series Coal Fired Boiler Efficiency
Product thermal capacity: 2-10 t/h
Working pressure: 1-2.5 MPa
Available fuel: Bituminous coal,lean coal,anthracite
Available industries: Heating, chemical, food, tobacco, textile, printing and dyeing, feed, medicine, building material, wine, rubber, hospital
DZL Series Coal Fired Boiler Introduction
DZL Series Coal Fired Boiler Features
High-efficiency combustion system: Our coal-fired boilers are equipped with an advanced combustion system that optimizes the combustion process and control, achieving more complete combustion and higher combustion efficiency. This not only improves the thermal efficiency but also reduces pollutant emissions generated by combustion.
High-efficiency heat exchange system: Our coal-fired boilers employ an optimized heat exchanger design, improving the efficiency of heat transfer. The use of threaded smoke tubes increases the heat transfer coefficient by 1.8 times compared to ordinary smoke tubes.
Advanced control system: Our coal-fired boilers are equipped with an advanced automatic control system that monitors and adjusts the combustion process and boiler operating parameters. This intelligent control system optimizes combustion and heat exchange in real-time, maintaining the boiler in its optimal working state and improving overall efficiency.
Environmental friendliness and sustainability: Our coal-fired boilers comply with environmental requirements and utilize advanced combustion and exhaust gas treatment technologies, reducing emissions of pollutants. Moreover, by improving energy utilization efficiency, our boilers reduce the demand for limited resources such as coal, promoting sustainable development.
DZL Series Coal Fired Boiler Specification
Model | Rated steam capacity (t/h) | Rated working pressure (MPa) | Rated steam temperature (℃) | Thermal efficiency (%) | Maximum transport dimension (m) |
DZL2-1.25-AⅡ | 2 | 1.25 | 194 | >80 | 5.30×2.40×3.40 |
DZL2-1.6-AⅡ | 2 | 1.6 | 204 | >80 | 5.30×2.40×3.40 |
DZL2-2.5-AⅡ | 2 | 2.5 | 225 | >80 | 5.30×2.40×3.40 |
DZL4-1.25-AⅡ | 4 | 1.25 | 194 | >80 | 6.50×2.70×3.60 |
DZL4-1.6-AⅡ | 4 | 1.6 | 204 | >80 | 6.50×2.70×3.60 |
DZL4-2.5-AⅡ | 4 | 2.5 | 225 | >80 | 6.50×2.70×3.60 |
