YQW Series Hot Oil Boiler System

ZOZEN Hot Oil Boiler System

Product Thermal Capacity: 1400-14000 kW

Working Pressure:0.8-1.0 MPA

Available Fuel: Natural gas, coke oven gas, bio-gas, liquefied petroleum gas, diesel, heavy oil, light oil, crude oil

Available Industries: Petroleum, chemical, chemical fiber, pharmaceutical, textile printing and dyeing, building materials, wood processing, vegetable oil processing and other industries

YQW Series Hot Oil Boiler System Introduction

The YQW Series Hot Oil Boiler System adopts a two or three-pass coil design and is equipped with advanced burners and an automatic control system, ensuring efficient and stable heat energy output. The end of the coil tube is tapered, effectively protecting the end furnace wall of the boiler. It is equipped with advanced combustion equipment, and the operation of the boiler is fully automated. The boiler is assembled and delivered from the factory, facilitating transportation, installation, commissioning, and use.

YQW Series Hot Oil Boiler System Advantages

Fully Automatic Control: The YQW series hot oil boiler system utilizes PLC intelligent control to achieve functions such as automatic ignition, temperature regulation, and safety protection, making operation simple.

Easy Operation and Maintenance: The YQW series hot oil boiler system has a horizontal structure and is fully assembled at the factory, resulting in a short installation period and convenient operation and maintenance.

High-Quality Materials: The YQW series hot oil boiler system is manufactured using high-temperature and corrosion-resistant materials to ensure equipment reliability and durability.

Low Emissions: The YQW series hot oil boiler system reduces the emission of harmful substances by optimizing combustion design and employing an efficient flue gas treatment system, complying with environmental requirements.

YQW Series Hot Oil Boiler System Specification

Model Rated thermal power (KW) Rated thermal power (×104kcal/h) Rated outlet oil temperature (≤℃) Rated working pressure (MPa) Thermal efficiency (%)
YQ(Y)W-1400Q(Y) 1400 120 320 0.8 >92
YQ(Y)W-1800Q(Y) 1800 160 320 0.8 >92
YQ(Y)W-2100Q(Y) 2100 180 320 0.8 >92
YQ(Y)W-2400Q(Y) 2400 200 320 0.8 >92
YQ(Y)W-2800Q(Y) 2800 240 320 0.8 >92
YQ(Y)W-3500Q(Y) 3500 300 320 0.8 >92
YQ(Y)W-4200Q(Y) 4200 360 320 0.8 >92
YQ(Y)W-4600Q(Y) 4600 400 320 0.8 >92
YQ(Y)W-6000Q(Y) 6000 500 320 0.8 >92
YQ(Y)W-7000Q(Y) 7000 600 320 0.8 >92
YQ(Y)W-8200Q(Y) 8200 700 320 0.8 >92
YQ(Y)W-9400Q(Y) 9400 800 320 0.8 >92
YQ(Y)W-10500Q(Y) 10500 900 320 0.8 >92
YQ(Y)W-12000Q(Y) 12000 1000 320 0.8 >92
YQ(Y)W-14000Q(Y) 14000 1200 320 0.8 >92
