ZOZEN WNS Series 3 Pass Boiler

ZOZEN 3 Pass Boiler

Product thermal capacity: 1 – 20 t/h

Working pressure: 0.7-2 MPa

Available fuel: Natural gas, coke oven gas, biogas, diesel, heavy oil, light oil, crude oil, etc.

Available industries: Heat supplying, chemical, food, textile, printing and dyeing, cigarettes and tobacco, fodder, pharmacy, building materials, brewery, rubber, hospital etc.

WNS Series 3 Pass Boiler Introduction

The WNS series 3 pass boiler features a horizontal design with a compact structure and an aesthetically pleasing appearance. These boilers deliver efficient combustion performance and exceptional thermal energy utilization, making them an ideal choice for various industrial applications.

This innovative configuration ensures that the high-temperature flue gas generated during combustion releases heat progressively as it flows through three stages, maximizing thermal efficiency and reducing energy losses.

This advanced flow path not only enhances thermal efficiency but also effectively reduces flue gas temperatures, minimizing energy waste and maximizing operational efficiency.

WNS Series 3 Pass Boiler Advantages

High Efficiency and Energy Saving: The three pass design optimizes the flue gas flow and heat transfer process, boosting thermal efficiency to over 98%. The seamless integration of the burner and boiler ensures complete fuel combustion, significantly reducing energy consumption and operational costs.

Environmentally Friendly and Low Emissions: Equipped with advanced low-NOx burners, the 3 pass boiler employs optimized combustion technology to substantially lower NOx emissions. Its superior environmental performance complies with stringent regulatory requirements. The low-temperature flue gas discharge minimizes its environmental impact, making it an ideal choice for green and energy-saving operations.

Intelligent Operation: The 3 pass boiler features a fully automated control system with a smart touch panel and PLC control module, enabling comprehensive automation. Users can effortlessly monitor the boiler’s operating status and precisely adjust parameters such as temperature and pressure. This system ensures simple operation, safety, and reliability.

Easy Maintenance: The horizontal design of the WNS series 3 pass boiler ensures a small footprint and convenient installation. Manufactured with premium materials, the boiler guarantees durability and operational stability. Its scientifically arranged smoke tubes facilitate cleaning and inspection, simplifying maintenance tasks and reducing upkeep costs.

WNS Series 3 Pass Boiler Specification

Model Rated steam capacity (t/h) Rated working pressure (MPa) Rated steam temperature (℃) Maximum transport weight (t) Maximum transport dimension (m)
WNS1-0.7-Q(Y) 1 0.7 170 4.5 3.25×1.80×2.00
WNS1-1.0-Q(Y) 1 1 184 4.5 3.25×1.80×2.00
WNS1.5-1.0-Q(Y) 1.5 1 184 7 3.65×2.05×2.45
WNS1.5-1.25-Q(Y) 1.5 1.25 194 7 3.65×2.05×2.45
WNS2-1.0-Q(Y) 2 1 184 9 4.60×2.20×2.60
WNS2-1.25-Q(Y) 2 1.25 194 9 4.60×2.20×2.60
WNS3-1.0-Q(Y) 3 1 184 11.5 5.35×2.40×2.80
WNS3-1.25-Q(Y) 3 1.25 194 11.5 5.35×2.40×2.80
WNS4-1.25-Q(Y) 4 1.25 194 15 5.00×2.60×2.95
WNS4-1.6-Q(Y) 4 1.6 204 15 5.00×2.60×2.95
WNS5-1.25-Q(Y) 5 1.25 194 18 5.55×2.658×3.20
WNS5-1.6-Q(Y) 5 1.6 204 18 5.55×2.658×3.20
WNS6-1.25-Q(Y) 6 1.25 194 19.5 5.93×2.80×3.20
WNS6-1.6-Q(Y) 6 1.6 204 19.5 5.93×2.80×3.20
WNS8-1.25-Q(Y) 8 1.25 194 25 7.00×2.80×3.25
WNS8-1.6-Q(Y) 8 1.6 204 25 7.00×2.80×3.25
WNS10-1.25-Q(Y) 10 1.25 194 27.5 7.65×2.80×3.25
WNS10-1.6-Q(Y) 10 1.6 204 27.5 7.65×2.80×3.25
WNS15-1.25-Q(Y) 15 1.25 194 40 7.95×3.50×3.75
WNS15-1.6-Q(Y) 15 1.6 204 40 7.95×3.50×3.75
WNS20-1.25-Q(Y) 20 1.25 194 52 8.55×3.90×4.15
WNS20-1.6-Q(Y) 20 1.6 204 52 8.55×3.90×4.15
